Kingspan NSFA1000 - For Areas Up To 5,560m2


Regular price £7,860.00

Full retention separators treat the full flow that can be delivered by the drainage system, which is normally equivalent to the flow generated by a rainfall intensity of 65mm/hr. On large sites, some short term flooding may be an acceptable means of limiting the flow rate and hence the size of full retention systems.

Features and Benefits;

  • Light and easy to install
  • Inclusive of silt storage volume
  • Fitted inlet/outlet connectors
  • Vent points within necks
  • Extension access shafts for deep inverts
  • Maintenance from ground level
  • CE Marked
Flow L/S 100
Drainage Area m2 5560
Storage Capacity Silt 10,000L
Storage Capacity Oil 1000L
Length 6200mm
Diameter 2820mm
Inlet Invert 2500mm
Outlet Invert 2450mm
Pipework Size 400mm
  • Free delivery to mainland UK (excl. Scottish Highlands, please contact us for a delivery prices).
  • Customer is responsible for offloading the product from the delivery vehicle.
  • Delivery dates are subject to change.
