Kingspan NSFA010 - For Areas Up To 555m2

Kingspan

Regular price £2,030.00

Full retention separators treat the full flow that can be delivered by the drainage system, which is normally equivalent to the flow generated by a rainfall intensity of 65mm/hr. On large sites, some short term flooding may be an acceptable means of limiting the flow rate and hence the size of full retention systems.

Features and Benefits;

  • Light and easy to install
  • Inclusive of silt storage volume
  • Fitted inlet/outlet connectors
  • Vent points within necks
  • Extension access shafts for deep inverts
  • Maintenance from ground level
  • CE Marked
  • GRP or rotomoulded construction (rotomoulded for NSFP003 and NSFP006)
Flow L/S 10
Drainage Area m2 555
Storage Capacity Silt 1000L
Storage Capacity Oil 100L
Length 2610mm
Diameter 1225mm
Inlet Invert 1050mm
Outlet Invert 1000mm
Pipework Size 200mm
  • Free delivery to mainland UK (excl. Scottish Highlands, please contact us for a delivery prices).
  • Customer is responsible for offloading the product from the delivery vehicle.
  • Delivery dates are subject to change.
