Kingspan NSFA040 - For Areas Up To 2,225m2

Kingspan

Regular price £4,800.00

Full retention separators treat the full flow that can be delivered by the drainage system, which is normally equivalent to the flow generated by a rainfall intensity of 65mm/hr. On large sites, some short term flooding may be an acceptable means of limiting the flow rate and hence the size of full retention systems.

Features and Benefits;

  • Light and easy to install
  • Inclusive of silt storage volume
  • Fitted inlet/outlet connectors
  • Vent points within necks
  • Extension access shafts for deep inverts
  • Maintenance from ground level
  • CE Marked
Flow L/S 40
Drainage Area m2 2225
Storage Capacity Silt 4000L
Storage Capacity Oil 400L
Length 4640mm
Diameter 2010mm
Inlet Invert 1810mm
Outlet Invert 1760mm
Pipework Size 315mm
