Kingspan NSFA080 - For Areas Up To 4,445m2
Kingspan
Regular price £8,953.20
Full retention separators treat the full flow that can be delivered by the drainage system, which is normally equivalent to the flow generated by a rainfall intensity of 65mm/hr. On large sites, some short term flooding may be an acceptable means of limiting the flow rate and hence the size of full retention systems.
Features and Benefits;
- Light and easy to install
- Inclusive of silt storage volume
- Fitted inlet/outlet connectors
- Vent points within necks
- Extension access shafts for deep inverts
- Maintenance from ground level
- CE Marked
Flow L/S | 80 |
Drainage Area m2 | 4445 |
Storage Capacity Silt | 8,000L |
Storage Capacity Oil | 800L |
Length | 5744mm |
Diameter | 2820mm |
Inlet Invert | 2500mm |
Outlet Invert | 2450mm |
Pipework Size | 300mm |
